20-ton underground mining dump truck designed for maximum payload efficiency, featuring strong traction and reliable air brake system for deep mining projects.
Send Inquiry

Technical Specifications

Model
20 Ton Wheeled Mining Dump Truck
Engine model
Yuchai 4108 intercooled turbocharged 160HP
Transmission
10JS90 transmission
Axle model
Front axle 153 (10 holes) and rear axle 153 (10 holes)
Bucket size
4 × 2.2 × 0.8 m
Bucket board
Bottom 10mm, sides 8mm
Tire
900-20 Kunlun Mining Steel Wire Tire
Frame model
24 8+8 riveted frame
Spring plate
Front 12 leaves, rear 10+8 leaves, 90mm × 16mm
Hydraulic cylinder
130 × 1200 mm
Braking method
Wet Brake
Steering mode
Hydraulic steering assistance
Tail gas treatment
Water washing exhaust treatment
Driving style
Left side driving
Cabin
1.4 × 1.5m thickened steel plate, single person semi closed cabin
Total size
5.6 × 2.3 × 2 m (length × width × height)
Machine height
2 m
Shift mode
Gear shift cable

Products Description

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

Shandong Beijun Heavy Industry Co., Ltd. is a high-tech enterprise specializing in mining and roadway transportation for over 12 years. Located in Jining City, a key industrial hub in Shandong Province, the company covers an area of over 200 acres with a total investment of 300 million RMB.

We integrate R&D, production, sales, and service, focusing on providing high-quality mining transportation solutions. Our main products include mining dump trucks, trackless rubber-wheeled passenger vehicles, and service vehicles, widely used in underground mining operations such as ore transport, personnel commuting, and equipment support.

Equipped with 172 advanced production and testing machines—such as CNC machining centers, laser cutters, welding robots, and coating lines—we achieve an annual output of 5,000 mining dump trucks. Our products are exported to more than 20 countries, including markets in the Middle East, Africa, and Southeast Asia.

We hold certifications including ISO9001, ISO14001, ISO45001, and EU CE, and own over 20 technical patents. Our products meet national mining safety standards and are trusted by customers across China, with a repurchase rate of 74%.

With a strong commitment to quality, innovation, and customer service, Beijun Heavy Industry is dedicated to becoming a globally recognized brand in mining transportation equipment, helping customers improve efficiency and reduce costs.

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

20-Ton Underground Mining Dump Truck for Large-Scale Mining with Full Air Brake

FAQ

1. Are you a manufacturer or trading company?

We are a professional manufacturer of underground mining equipment with extensive experience in design, production and global export.

2. What mining equipment do you supply?

We supply underground mining dump trucks, scaling jumbos, tunneling jumbos, wet shotcrete spraying rigs and rock drilling jumbos.

3. What applications are your machines suitable for?

Our equipment is widely used in underground mining, tunneling, hydropower projects and other underground construction applications.

4. Do you provide customized solutions?

Yes. We offer OEM and customized solutions based on tunnel size, rock conditions, haulage capacity and project requirements.

5. What certifications do your products have?

Our equipment can be supplied with CE and other certifications according to your market requirements.

6. What is your delivery time?

Standard delivery time is typically 20–60 days depending on model, quantity and customization requirements.

7. What payment terms do you accept?

We accept T/T, L/C and other payment methods upon mutual agreement.

8. Do you provide spare parts and after-sales support?

Yes. We provide spare parts, technical documentation, remote support and comprehensive after-sales service.

9. Which countries do you export to?

Our mining equipment is exported to Europe, Southeast Asia, the Middle East, Africa and South America.

10. How can I get a quotation?

Send us your required model, technical specifications and project details, and we will provide a quotation within 24 hours.
